Persian Sanat Mabna loding Ramp

The biggest concern in any industrial workshop is not to damage the raw materials or finished products. Most of the damage to the product occurs during loading or unloading. This is mainly due to the difference between the level of the freight truck and the loading levels.

In this way, automatic loading ramp systems will be very useful. The use of automatic loading ramps not only reduces loading damage to the goods but also minimizes the exchange of energy and heat from the workshop by using loading tents.

The loading or intermediate ramp can solve all the needs of the counter for loading and unloading. Slowly

Technical specifications of telescopic ramp:

The edge of the system can be designed telescopically up to 1500 mm. It depends on your needs. In making this ramp, non-welded reinforced steel sheets up to 3000 mm are used. It has a safety valve for blocking hydraulic oil to lock the hydraulic jack. The whole system works electro-hydraulically.

Can be installed on all levels.

The whole system is designed and built in accordance with the CE standard.

The telescopic traction surface has properties similar to hinged lips and is used to load the unloading of container vehicles, which is accompanied by rubber bumpers. Its motor type is hydraulic.

Application specifications:

To speed up loading and the possibility of loading by forklift on the platforms of food factories; Cold houses and ...
